技術特點:
1. Clear displayofvarious working states on the touch screen,operationindicator lights, easy and intuitive operation.
觸摸屏清楚顯示各工作狀態、操作指示燈，操作簡便直觀。
2. Can accommodate 10 product formulas for quick packaging changes.
可預置10個產品的配方，適應快速更換產品包裝。
3. Using a temperature controller, the temperature differencecan be controlled within 2 °C.
采用智能溫控器，溫差可控制在2°C以內。
4. The sealing position and deviation correction can bedirectly adjusted on the touch screen without stopping the machine.不停機可直接在觸摸屏上調整封切位置和糾偏。
5. Paired with a horizontal toothed seal, the packaging is more secure, Youcan also choose straight, twill, mesh, etc.
配合橫紋齒型封口，包裝更加牢固;還可選用直紋、斜紋、網紋等。
6. This device can produce various bag types, such as flat seals, handbags.punched bags, etc.
該設備能制多種袋型，如平面封、手提袋、沖孔袋。
7. If the packaging film is made of single-layer PE material, a special PE filmsealing device can be optionallyequipped.如果包裝膜是單層的PE材料，可選配特殊PE膜專用封口裝置。
技 術 參 數 ：
| 機 型(TYPE) | RH-420 |
| 制袋長度(Bag length) | 80-420mm(L) |
| 制袋寬度(Bag width) | 100-200mm(w) |
| 薄膜寬度(Max width of roll film | 420mm |
| 包裝速度(Packing speed) | 20-60bag/min |
| 氣壓(Air consumption) | 0.65mpa |
| 耗氣量(Gas consumption) | 0.4m/min |
| 電壓(Power voltage) | 220V/50HZ |
| 功率(Power) | 3.0KW |
| 外型尺寸(Dimension) | (L)2088mmx(w)2088mmx(H)3800mm |
| 機器重量(Machine weight ) | 1200kg |
